060245L-VAF

"NAME:AUXILARY ENGINE FLOWMETER

MAKER:VAF INSTRUMENTS B.V

TYPE:B5025 PROFLOW VANE METER

SERIAL NO:ANNEXE 109300/30" "A/E FLOWMETER

MEDIUM : HFO

WORKING PRESSURE ; 4 KG/CM²

TEMPARATURE : MAX 150 °C

FLOWRANGE : 38/152/800 L/H

PRODUCT SPECIFICATIONS

MAYERIAL HOUSING  : DUCTILE IRON

MATERIAL VANES : SINTERED CARBON

SIZE : 25 MM

FLOWRANGE : 0.120 LITRE /MIN (24 HR / DAY)

                        :0.160  LITRE /MIN (24 HR / DAY)

WORKING PRESSURE : MAXIMUM 25 BAR

CONNECTIONS : FLANGE , JIS 16K

MATERIAL BEARING : STEEL

MATERIAL SEALING : VITON

FLOW DIRECTION : RIGHT TO LEFT

WORKING TEMPARATURE : -15 TO 125 °C

COUNTER : MECHANICAL 6 DIGITS , NOT RESETABLE

SMALLEST READ OUT : 0.1 LITRE

MATERIAL CERTIFICATE NUMBER : EN 10204-3.1.B" VAF INSTRUMENTS.NA.109300/30
