060243L-VAF

"NAME:MAIN ENGINE FLOWMETER

MAKER:AF INSTRUMENTS B.V

TYPE:B5040 PROFLOW VANE METER

SERIAL NO:ANNEXE 109300/20

" "M/E FLOWMETER

MEDIUM : HFO

WORKING PRESSURE ; 4 KG/CM²

TEMPARATURE : MAX 150 °C

FLOWRANGE : 330/2412/3600 L/H

PRODUCT SPECIFICATIONS

MAYERIAL HOUSING  : DUCTILE IRON

MATERIAL VANES : SINTERED CARBON

SIZE : 40 MM

FLOWRANGE : 0.190 LITRE /MIN (24 HR / DAY)

                        :0.250  LITRE /MIN (24 HR / DAY)

WORKING PRESSURE : MAXIMUM 25 BAR

CONNECTIONS : FLANGE , JIS 16K

MATERIAL BEARING : STEEL

MATERIAL SEALING : VITON

FLOW DIRECTION : RIGHT TO LEFT

WORKING TEMPARATURE : -15 TO 125 °C

COUNTER : MECHANICAL 6 DIGITS , NOT RESETABLE

SMALLEST READ OUT : 0.1 LITRE

MATERIAL CERTIFICATE NUMBER : EN 10204-3.1.B" VAF INSTRUMENTS.NA.109300/20
