090693V-V200

"Spare parts for Main Air Compressor have been ordered for overhaul and replenish stock level.

Type V200

Ser.No.05.2191-1-0

Description Two Stage, Twin Cylinder in a 90o Vee Format

Capacity 200m3/hr FAD

Pressure 30barg

Speed 1800rpm

Shaft 38kW

Unloading Automatic via 1st and 2nd Stage Solenoid Valves

Control Voltage 110V

Lubrication splash

Cooling Type Fresh Water up to 7bar Maximum Pressure

Motor

Rated Power 0.28kW

Speed 3312rpm

Starting Current 4.0Amps

Full Load Current at 460V 0.9Amps" PISTON 2ND STAGE(COMPL) HATLAPA.V200
