1025124J-KDH

"MAKER: KUK DONG IND., ENG.;

MODEL: KDH-16;

DRAWING NO: KDH-16

" "BALLAST STRIPPING EDUCTOR COMPLETE

""CONNECTION:

1)DRIVING SIDE : JIS 10kg/cm2 125 A

2)SUCTION SIDE : JIS 10kg/cm2 150 A

3)DISCHARGE SIDE : JIS 10kg/cm2 200 A

SUCTION HEAD: -0.5kg/cm2G

DISCHARGE HEAD: 1.6kg/cm2G

SUCTION CAPA: 150 m3/hr

DRIVING WATER CONSUMPTION: 170 m3/hr x 9 kg/cm2G

" KUK DONG.KDH-16.01-07

"MAKER: KUK DONG IND., ENG.;

MODEL: KDH-16;

DRAWING NO: KDH-16

" "GASKET

" KUK DONG.KDH-16
