MAN B&W DIESEL ENGINE PARTS 6L16/24

TYPE:6L16/24[ENGINE RPM 1200]

 1 T/C CATRIDGE Part No.: 599.000

 2 TURBINE NOZZLE RING Part No.: 001-513.001

 3 INJECTION NOZZLE ( L’ORANGE ) FOR 1200 RPM Part No.: 51402-08H-021

 4 FUEL INJECTOR COMPLETE Part No.: 51402-08H-116

 5 KIT FOR CYCLINDER UNIT Part No.: 50500-04H-21

 6 FLAME RING Part No.: 50610-03H-092

 7 VALVE SPINDLE EXHAUST Part No.: 50502-03H-262

 8 VALVE SPINDLE INLET Part No.: 50502-03H-274

 9 VALVE GUIDE Part No.: 50501-11S-088

 10 O RING Part No.: 50501-11S-076

 11 BARREL Part No.: 51401-07H-099

 12 PLUNGER Part No.: 51401-07H-109

 13 SEAL KIT FOR FUEL P/P Part No.: 51401-07H-839

 14 AE FUEL NOZZLE TEST PUMP Part No.: 52014-02H-050

 15 VALVE SEAT RING (EXHAUST) Part No.: 50501-01H-076C

 16 O-RING Part No.: 50501-01H-184

 17 O-RING Part No.: 50501-01H-338??

 18 O-RING Part No.: 50501-01H-351?

 19 O-RING Part No.: 50501-01H-363

 20 GASKET Part No.: 50510-01H-075?

 21 GASKET Part No.: 50510-01H-026

 22 NUT Part No.: ?50502-01H-095

 23 ROTOCAP COMPLETE Part No.: 50502-01H-477?

 24 VALVE SPINDLE INLET & OUTLET Part No.: 50502-01H-512??

 25 O-RING? Part No.: 50801-01H-185??

 26 PISTON PIN COMPLETE Part No.: 50601-02H-019B

 27 RETAINING RING? Part No.: 50601-02H-032

 28 BUSH FOR CONNECTING ROD? Part No.: 50601-02H-056

 29 PISTON Part No.: 50601-02H-081

 30 PISTON RING IST Part No.: 50601-02H-093

 31 PISTON RING SECOND Part No.: 50601-02H-103

 32 PISTON RING THIRD Part No.: 50601-02H-115

 33 OIL SCRAPER RING Part No.: 50601-02H-127

 34 CONNECTING ROD BOLT Part No.: 50601-02H-152

 35 SEALING RING Part No.: 50610-02H-03

 36 O-RING Part No.: 50610-02H-043

 37 PACKING Part No.: 51202-02H-024/1

 38 COOLING WATER NIPPLE??? Part No.: 51202-02H-252

 39 O-RING Part No.: 51202-02H-264

 40 COOLING WATER NIPPLE Part No.: 50501-01H-196

 41 SCREW Part No.: 51202-02H-036

 42 O-RING Part No.: 51402-01H-116

 43 NOZZLE COMPLETE Part No.: 51402-01H-033?

 44 SPRING Part No.: 51402-01H-082

 45 FUEL INJECTION PIPE COMPLETE Part No.: ?51404-01H-010

 46 O-RING? Part No.: 51404-01H-130?

 47 O-RING? Part No.: 51404-01H-178

 48 SEALING RING? Part No.: 51404-01H-166?

 49 O-RING Part No.: 51403-01H-064

 50 FILTER ELEMENT COMPLETE Part No.: 51403-01H-027

 51 ROTATING SEALING Part No.: 51610-02H-083A

 52 SEALING RING Part No.: 51610-02H-095

 53 BALL BEARING Part No.: 51610-02H-105?

 54 RETAINING RING? Part No.: 51610-02H-117B

 55 SEALING RING Part No.: 51203-01H-234?

 56 SAFETY ELEMENT Part No.: 51502-O1H-025

 57 LUB OIL THERMOSTATIC ELEMENT(WAX TYPE) SETTING60 DEG.CEL. Part No.: 51503-01H-032?

 58 O-RING Part No.: 51503-01H-020/2

 59 O-RING Part No.: 51503-01H-044?

 60 SLEEVE Part No.: 51503-01H-056?

 61 COOLING WATER THERMOSTATIC ELEMENT(WAX TYPE) SETTING 80 DEG.CEL. Part No.: 51604-01H-043

 62 O-RING Part No.: 51604-01H-031

 63 O-RING Part No.: 51604-01H-055??

 64 SLEEVE Part No.: 51604-01H-067?
