MAN B&W SPARE PARTS S50MC-C

TYPE：S50MC-C

 1 o-ring Part No.: 90101-158-114

 2 connecting piece Part No.: 90103-55-19

 3 gasket Part No.: 90103-55-20

 4 gasket Part No.: 90103-55-68

 5 indicator cock Part No.: 90103-55-81

 6 locking plate Part No.: 90103-55-103

 7 o-ring Part No.: 90302-184-117

 8 gasket Part No.: 90302-184-22

 9 piston cleaning ring Part No.: 90302-184-34

 10 cooling water pipe Part No.: 90302-184-213

 11 o-ring(viton) Part No.: 90302-184-201

 12 packing Part No.: 91003-186-437

 13 gasket Part No.: 90801-206-13

 14 gasket Part No.: 90801-206-62

 15 o-ring Part No.: 90801-206-108

 16 bottom piece Part No.: 90801-206-121

 17 sealing ring(u-cup) Part No.: 90801-206-133

 18 spindle guide lower Part No.: 90801-206-204

 19 gasket Part No.: 90801-206-228

 20 spring pin Part No.: 90801-206-253

 21 sealing ring Part No.: 90801-206-277

 22 o-ring(viton) Part No.: 90801-206-289

 23 thread insert Part No.: 90801-206-300

 24 gasket Part No.: 90801-206-324

 25 o-ring(viton) Part No.: 90803-40-158

 26 packing Part No.: 90803-40-242

 27 non-return valve Part No.: 90803-40-301

 28 orifice plug Part No.: 90803-40-313

 29 plug screw Part No.: 90803-40-325

 30 o-ring(nbr) Part No.: 90803-40-337

 31 guide ring Part No.: 90803-40-374

 32 sealing ring Part No.: 90803-40-386

 33 screwed connection Part No.: 90803-40-469

 34 gasket Part No.: 90803-40-470

 35 o-ring(nbr) Part No.: 90803-40-482

 36 spring Part No.: 90803-40-494

 37 spring retainer Part No.: 90803-40-504

 38 spring pin Part No.: 90803-40-516

 39 rotation check rod Part No.: 90803-40-528

 40 non return valve Part No.: 90803-40-541

 41 Locking wire Part No.: 90803-40-553

 42 conical ring in 2/2 Part No.: 90803-40-577

 43 piston,complete Part No.: 90803-40-648

 44 piston ring Part No.: 90803-40-661

 45 gasket Part No.: 90804-16-21

 46 safety valve,complete Part No.: 90804-16-45

 47 o-ring Part No.: 90804-16-905

 48 thrust disc Part No.: 90805-141-64

 49 bushing Part No.: 90805-141-135

 50 disc Part No.: 90805-141-147

 51 o-ring(viton) Part No.: 90805-141-172

 52 guide pin Part No.: 90805-141-184

 53 piston ring Part No.: 90805-141-231

 54 disc Part No.: 90805-141-243

 55 spring seat disc Part No.: 90805-141-267

 56 spring(length=261.7mm) Part No.: 90805-141-279

 57 key Part No.: 90805-141-292

 58 hydraulic pipe,complete Part No.: 90806-105-10

 59 o-ring(nbr) Part No.: 90806-105-142

 60 o-ring(viton) Part No.: 90806-105-166

 61 retaining ring Part No.: 90806-105-178

 62 retaining ring Part No.: 90806-105-191

 63 sleeve in 2/2 Part No.: 90806-105-201

 64 intermediate piece Part No.: 90806-105-213

 65 o-ring(viton) Part No.: 90806-105-225

 66 gasket Part No.: 90806-105-249

 67 o-ring(viton) Part No.: 90806-105-262

 68 cooling water connection Part No.: 90806-105-286

 69 thrust piece Part No.: 90910-148-16

 70 CUT-OFF SHAFT Part No.: 90910-148-41

 71 SPINDLE GUIDE Part No.: 90910-148-53

 72 atomizer(4X1.15) Part No.: 90910-148-65

 73 o-ring(viton) Part No.: 90910-148-89

 74 guide pin Part No.: 90910-148-100

 75 o-ring(viton) Part No.: 90910-148-124

 76 o-ring(viton) Part No.: 90910-148-148

 77 guide pin Part No.: 90910-148-173

 78 spring Part No.: 90910-148-185

 79 non-return valve,complete Part No.: 90910-148-197

 80 thrust spindle Part No.: 90910-148-219

 81 spring Part No.: 90910-148-220

 82 disc(0.75mm) Part No.: 90910-148-950

 83 gasket Part No.: 90704-60-28

 84 piston Part No.: 90704-60-53

 85 piston Part No.: 90704-60-65

 86 spring Part No.: 90704-60-77

 87 o-ring Part No.: 90704-60-124

 88 valve spindle Part No.: 90704-60-136

 89 valve flap Part No.: 91101-37-83

 90 valve guide m22x1.5 Part No.: 91101-37-95

 91 safety valve, complete Part No.: 91101-37-117

 92 locking wire Part No.: 90201-204-47

 93 screw Part No.: 90201-204-60

 94 piston ring NRP Part No.: 90201-204-84

 95 piston ring NRP Part No.: 90201-204-96

 96 piston ring NPR Part No.: 90201-204-106

 97 d-ring(viton) Part No.: 90201-204-167

 98 d-ring(viton) Part No.: 90201-204-179

 99 scraper ring Part No.: 90205-115-37

 100 scraper ring Part No.: 90205-115-49

 101 guide pin Part No.: 90205-115-62

 102 spring pin Part No.: 90205-115-98

 103 lamella Part No.: 90205-115-121

 104 o-ring Part No.: 90205-115-145

 105 top scraper ring Part No.: 90205-115-157

 106 cover sealing ring Part No.: 90205-115-169

 107 pack sealing ring Part No.: 90205-115-170

 108 fitted bolt Part No.: 90205-115-204

 109 spring Part No.: 90205-115-241

 110 spring Part No.: 90205-115-253

 111 o-ring Part No.: 90302-184-117

 112 o-ring(viton) Part No.: 90302-184-129

 113 cooling water connection Part No.: 90302-184-166

 114 gasket Part No.: 90302-184-178

 115 non-return valve,complete Part No.: 90304-37-11

 116 packing ring Part No.: 90702-70-123

 117 packing ring Part No.: 90702-70-135

 118 spring Part No.: 90702-70-231

 119 spindle Part No.: 90702-70-243

 120 packing ring Part No.: 90702-70-302

 121 guide pin Part No.: 90702-70-351

 122 gasket Part No.: 90702-70-434

 123 non-return va Part No.: 90702-70-529

 124 repair kit Part No.: 90702-70-900

 125 repair kit Part No.: 90702-70-924

 126 repair kit Part No.: 90702-70-936

 127 repair kit Part No.: 90702-70-948

 128 sealing ring Part No.: 90703-107-191

 129 o-ring(viton) Part No.: 90703-107-213

 130 plate-round Part No.: 90901-203-30

 131 plug screw Part No.: 90901-203-42

 132 packing Part No.: 90901-203-54

 133 plug screw Part No.: 90901-203-66

 134 guide pin Part No.: 90901-203-78

 135 toothed bar Part No.: 90901-203-125

 136 shim Part No.: 90901-203-149

 137 guide pin Part No.: 90901-203-162

 138 gasket Part No.: 90901-203-198

 139 plug screw Part No.: 90901-203-208

 140 steel ball Part No.: 90901-203-221

 141 cup point screw Part No.: 90901-203-233

 142 o-ring(viton) Part No.: 90901-203-257

 143 back-up ring Part No.: 90901-203-269

 144 plunger Part No.: 90901-203-270

 145 union nut Part No.: 90901-203-294

 146 pointer Part No.: 90901-203-304

 147 fuel pump complete Part No.:

 148 felt ring Part No.: 90901-203-316

 149 top cover Part No.: 90901-203-341

 150 guide pin Part No.: 90901-203-353

 151 o-ring Part No.: 90901-203-365

 152 back-up ring Part No.: 90901-203-377

 153 o-ring(viton) Part No.: 90901-203-389

 154 pump barrel Part No.: 90901-203-390

 155 o-ring(viton) Part No.: 90901-203-485

 156 sealing ring Part No.: 90901-203-497

 157 combined puncture and suction valve,complete Part No.: 90901-203-772

 158 bushing Part No.: 90902-144-85

 159 disc Part No.: 90902-144-97

 160 shaft-pin for roller Part No.: 90902-144-107

 161 thrust disc Part No.: 90902-144-144

 162 locking nut Part No.: 90902-144-384

 163 sealing ring Part No.: 90902-144-418

 164 scraper ring,axial Part No.: 90902-144-431

 165 locking wire Part No.: 90902-144-467

 166 packing Part No.: 90902-144-526

 167 disc Part No.: 90902-144-587

 168 spring seat disc Part No.: 90902-144-646

 169 o-ring(viton) Part No.: 90902-144-671
