032088C-GL100

FOR TANK LEVEL GAUGING SYSTEM

MAKER: KONGSBERG NORCONTROLLEVEL SENSING UNIT，DWG NO:P-GL100/CE.971027,LEVEL SENSING UNIT

Frequency: X-band

Radiated power: < 0.2 mW (-7 dBm)

Materials: AISI 316 in houshing and connetion box

               Teflon (PTFE) plate facing the cargo

 AISI 316L in tank adapter

Dimensions: H = 162 mm, Æ1 = 295 mm, Æ2 = 245 MM,

antena diameter = 200 mm

Weight: 29 kg

Protection: IP67

Enviromental temperature: - 40°C to + 80°C

KONGSBERG.GL-100.GLA-100

SINGAL PROCESSING UNIT，KONGSBERG, Autronica  no.: P-GL100/CE 971027,SIGNAL PRECESSING UNIT

Power Supply: 24 DC V (19 - 32 V)

Power Consumption: Max. 9.6 W

Heat Dissipation: Max. 5 W

Dimension: 38 x 382 x 152 mm

Communication: LONMARK network (ring-structure)

Input/Output: 1 radar input                                                                          4 Analogue 4-20 mA inputs                                                     4 open collector (PTC) galvanically isolated

4 analogue 4-20 mA inputs

4 open collector outputs (PTC) galvanically Isolated

Zener Barriers: Integrated

KONGSBERG.GL-100.GLK100

MODEL:GL-100

LEVEL GAUGE,DWG NO:P-GL100/CE.971027,General, LEVEL GAUGE

Measuring range: 0.3 to 40 m

Accuracy: ± 2 mm

Max trim/list: ± 4°

Ex classification: Eex ia IIC T4, Class 1, Division 1 Group A, B, C, D

Quality standard: ISO 9001

Generic EMC standard: Emission: EN50081-1

Immunity: EN50082-2

KONGSBERG.GL-100.GL-100
