032147L-PROPULSION

MARINE PROPULSION SYSTEMS  ZF

Propeller system  KH-850FUNNEL VENT LOUVER OPERATING DEVICE

NA.NA.25

BALL

NA.NA.30

ROTOR

NA.NA.32

FIRE PROOF DOOR A-60 IN ENGINE ROOM.

DIMENSIONS: HEIGHT - 1840 MM; WIDTH - 790 MM; THICK-47 MM

( LEFT HAND DOOR  )

NA.NA.33

D DECK STBD SIDE WT NO: 34

NA.NA.34

CYLINDER HEAD GASKET

NA.NA.36

PELORUS

FOR GYRO REPEATER

GYRO COMPASS ANSCHUTZ STD 22 PELORUS; HIGHT = 1250 MM,

DIAM OF BEARING REPEATER =245 MM;

PELORUS HIGHT=1250 MM; REPEATER DIAM = 245 MM; PELORUS DIAM = 445 MM

NA.NA.37

ZF-Reference number 98277

ZF serial number  CPP00016

Number of blades  4

Propeller hub size 850mm

Propeller diameter 3200mm

Stern tube temperature transducer type : PT 100

AFT stern tube seal  IHC size:355 = semi split with 4 th ring

FWD stern  tube seal  IHC size :350  =  std supreme- non split

25600101644 SIGNAL TRANSMISSION BOX

COMPLETE TOGETHER WITH

PROXIMITY SWITCH

-,PART NO: 23

ASSEMBLY: AIR-ACTUATED

QUICK CLOSING VALVE (1

MPA)TYPE QSA16080, DN80,

TAG: FDV35 M/E FO INLETB:

24, D: 200, L: 310, L1: 170, L2:

13

NA.NA.23
