0403131T-TME-231264

SHINKO IND. LTD.SEAL RING

SHINKO.KV450-3A.54A-4PACKING RING

SHINKO.KV450-3A.372

PACKING RING

SHINKO.KV450-3A.425

PACKING RING

SHINKO.KV450-3A.426

PACKING RING

SHINKO.KV450-3A.427

PACKING RING

SHINKO.KV450-3A.428

PACKING RING

SHINKO.KV450-3A.429

PACKING RING

SHINKO.KV450-3A.54A-5

SPRINGSTOPPER RING & SET SCREW

SHINKO.KV450-3A.54B-7

SPRING part

SHINKO.KV450-3A.54B-6

PACKING RING

SHINKO.KV450-3A.54B-5

SEAL RING

SHINKO.KV450-3A.54B-4

PACKING RING

SHINKO.KV450-3A.54B-2

FLOATING SEAT

SHINKO.KV450-3A.54B- 1

PACKING

SHINKO.KV450-3A.54B-3

OIL SEAL

SHINKO.KV450-3A.46-3

OIL SEAL

SHINKO.KV450-3A.46-4

PACKING RING

SHINKO.KV450-3A.57

SHINKO.KV450-3A.54A-6

STOPPER RING & SET SCREW

SHINKO.KV450-3A.54A-7

PACKING

SHINKO.KV450-3A.54A-3

CARGO OIL PUMP BALL BEARING #6324

SHINKO.KV450-3A.412

GLAND PACKING

SHINKO.KV450-3A.415

FLOATING SEAT

SHINKO.KV450-3A.54A- 1

PACKING RING

SHINKO.KV450-3A.54A-2

MODEL KV450-3A

CAPACITY 3800m3/h

TOTAL HEAD 135m

DISCHARGE HEAD 128.46m

SUCTION HEAD -5m

VELOCITY HEAD 1.54m

PUMPING LIQUID: CRUDE OIL & SW

SPEED (+/- 3%) 1280min-1

SERIAL# 1128783

FINAL DRAWING FOR CARGO PUMPING SYSTEM INDEX A

SHINKO IND.LTD.

5-7-21, OHZU, MINAMI-KU, HORISHIMA, JAPAN

DROWING NO. : KM-40001WA, KM-45302A

BALL BEARING #6319C3

SHINKO.KV450-3A.35
