040472V-WOV300

Pump Model: WOV- 300

Type: Vertical Reciprocating

Pump Maker: NANIWA PUMP MFG.CO., LTD.

Suction Bore/ Delivery Bore: 250 mm

Capacity: 250 m3/ h

Total Head: 130 m

Suction Head: -5 m

Length of stroke: 420 mm

No of Stroke: 29 s/ min

Dia of Steam cylinder: 480 mm

Dia of Pump cylinder: 360 mm

Feed Steam bore: 80 mm

Exh. Steam bore: 125 mm

Steam Consumption: abt. 3900 kg/ hr

Sectional Drawing: DWG No: A4CS0013

Item 1- Gland Packing, Dwg: A4CS0013, Part No 2, Quantity- 4 Sets

Item 2- Pump Valve Seat(Suc./Del.), Dwg: A4CS0013, Part No 21, Quantity- 8 Pcs

Item 3- Piston Ring,Gold Power, Dwg: A4CS0013, Part No 38, Quantity- 4 Pcs

Item 4- Gland Packing, Dwg: A4CS0013, Part No 42, Quantity- 2 Sets

Item 5- Gland Packing, Dwg: A4CS0013, Part No 53, Quantity- 2 Sets

Item 6- Gland Packing, Dwg: A4CS0013, Part No 56, Quantity- 2 Sets

Item 7- Bucket Ring, Viton Impregnated Cloth, Dwg: A4CS0013, Part No 61, Quantity- 4 Pcs

BUCKET RING, RUBBER IMPREGNATED CLOTH

NANIWA.WOV-300.061/A1CS0018
