Product Details

"FINAL DRAWING FOR CARGO PUMPING SYSTEM. HYUNDAI HEAVY INDUSTRIES LTD.

MANUAL: FINAL DRAWING FOR CARGO PUMPING SYSTEM

DRAWING #: 6T-9411-010

PAGE: A-5

DWG No: KC3-030327

TYPE: CVD40, Single Stage Steam Turbine Driven, Centrifugal

Serial #: H1873-C40-1/3

CAPACITY: 2750 m3/hr x 130 mTH

TOTAL: 130 m

Speed: 1510 rpm

NPSH Required: 4.2 m

BHP at SEA WATER: 1,188.7 kw

ROTATION VIEW: CCW

From driver

MAKER: HHI (HYUNDAI HEAVY INDUSTRIES CO., LTD) " "BALL BEARING

DWG:KC3-030327,POS.1430" SKF.CVD-40.6321-Z/C3
