0512106L-ALFA

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" "CENTRAL F.W COOLER (L.T)

UNITE TYPE: M20-MFM,

NO.PLATES /UNIT-185+1,  MIDIA: F.W/S.W, FLOW RATE-F.W-310 M³, FLOW RATE-S.W-361.5 M³, HEAT TRANSFERRED-4,600000, K-VALUE-6,788, LMTD-4.9 C, MAX DESIGN PRESS-6, MAX.DESIGN TEMP-90 C,

NO.OF PASSAGE-F.W-1, S.W-1,

NO.OF CHANNELS-83H+9ML

GASKET MATERIAL- NBR

MANUF.NO; 30108-62056,

GASKET-TI 0.5T/NBRP-CLIP-ON" "ALFA LAVAL.NA.DRAW-M2330136-B1

32330-2604-6"

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" "RUBBER LINING

NBR.MAX95 DEG.C" "ALFA LAVAL.NA.32330-6572-3

POS-29"

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" GASKET "ALFA LAVAL.NA.223336-08

POS-36"

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" RING GASKET ALFA LAVAL.NA.32330-2614-6

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" "MAIN L.O COOLER

UNITE TYPE: M20-MFM, NO.PLATES /UNIT-315,  MIDIA: LO/F.W, FLOW RATE-LO-295 M³, FLOW RATE-F.W-146M³, HEAT TRANSFERRED-946000, K-VALUE-405.4, LMTD-9.6 C, MAX DESIGN PRESS-6, MAX.DESIGN TEMP-90 C,

NO.OF PASSAGE-LO-1, F.W-1,

NO.OF CHANNELS-103H+54ML

GASKET MATERIAL- NBR

MANUF.NO; 30108-62055

GASKET-AISI304  0.5t/NBRP-CLIPP-ON" "ALFA LAVAL.NA.DRAW-M2330136-A,

32330-2604-6"

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" "RUBBER LINING

NBR.MAX95 DEG.C" "ALFA LAVAL.NA.32330-6572-3

POS-29"

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" GASKET "ALFA LAVAL.NA.223336-08

POS-36"

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" RING GASKET ALFA LAVAL.NA.32330-2614-6

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" "H.T F.W COOLER

UNITE TYPE: M10-MFM, NO.PLATES /UNIT-50,  MIDIA: HT F.W / F.W, FLOW RATE-HT F.W-115 M³, FLOW RATE-F.W-146M³, HEAT TRANSFERRED-1703000, K-VALUE-8286, LMTD-30.4 C, MAX DESIGN PRESS-6, MAX.DESIGN TEMP-90 C,

NO.OF PASSAGE-HT F.W-1, F.W-1,

NO.OF CHANNELS-1HT F.W-24L, F.W-25L

GASKET MATERIAL- NBR

MANUF.NO; 30108-62058

GASKET- AIS304  0.4t/NBRP-CLIP-ON" "ALFA LAVAL.NA.DRAW-M2330136-C

32330-1509-6"

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" RING GASKET-NBR ALFA LAVAL.NA.32330-6499-6

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" RUBBER LINING-NBR "ALFA LAVAL.NA.32330-6552-3

POS;32"

"NAME:PLATE TYPE HEAT EXCHANGER

TYPE:COOLERS GASKET

MAKER:ALFA LAVAL KOREA" GASKET "ALFA LAVAL.NA.223334-04

POS;39"
