Product Details

"Galley AC Unit

Maker: HEINEN&HOPMAN

Model: CSG25-BE9BF-4SF Serving Galley

Drawing No: 62019083-0350

Physical Data

Cooling capacity: 25kW

Refrigerant: R-407C

Power supply: 3x440V-60Hz

Compressor: Hermetically sealed scroll

Oil charge (POE): 1.77Ltr

Motor Rating: 5.94 kW

Condenser: Co-axial

Fresh water flow: 5.5m3/hr

Water Pressure Drop: 35 kPa

Evaporator: Fin & Tube

Airflow: 1500 m3/hr

External static. Press.: 600 Pa

Fan motor rating: 1.1 kW

Electric Heating: 9 kW

Refrigerant charge: 3.5 kg

Unit weight: 340 kg

Unit color: RAL 7035

Control Board (PCB)

Drawing: 62019083-SCU2-E" Control Board U1 Type: 3X1-Z03 (HTS-567-R) HEINEN&HORMAN.
