012962H-39650

"MAN B&W

L48/60B" "SKIRT,--

TYPE

PISTON.

ADDITIONAL DATA

PM PARTS, PISTON GROUP,

FOR UNIT# 10&11, M.A.N. DIESEL ENGINES,

MODEL 12V 4860B, SAMPLE S N 1135341 & 1135342,

ENGINE OUTPUT 12600 KW,

ENGINE SPEED 514RPM,

ENGINE DIRECTION CLOCKWISE,

MAN DIESEL

P/N#034.10.004" MAN B&W.L48/60B.034.10.004

"MAN B&W

L48/60B" Assembly cylinder liner MAN B&W.L48/60B.050.03.001

"MAN B&W

L48/60B" Valve rotating device MAN B&W.L48/60B.113.05.005

"MAN B&W

L48/60B" "O-RING,BULK NOUN

INSIDE DIAMETER

40.64 MM

OUTSIDE DIAMETER

51.3 MM

WIDTH

5.33 MM

MATERIAL

RUBBER

COLOR

GREEN

SERVICE

OIL

STANDARD/SPECIFICATION

ASTM

ADDITIONAL DATA

TYPE 16V25 30.PM PARTS,

FUEL INJECTION PUMP GROUP,

FOR UNIT# 10&11, M.A.N. DIESEL ENGINES,

MODEL 12V48 60B, SAMPLE SN 1135341 # 1135342,

ENGINE OUTPUT 12600 KW,

ENGINE SPEED 514 RPM,

ENGINE DIRECTION CLOCKWISE,

MAN DIESEL

P/N#200.02.031

MAN DIESEL

092-0012-0030" MAN B&W.L48/60B.200.02.031

"MAN B&W

L48/60B" "RING,BULK NOUN

PARENT EQUIPMENT/FUNCTION

BACKING SUPPORT

SIZE

(580 MM X 650 MM X 680 MM) ID X (830 MM X 850 MM)

OD X 580 MM HT

MATERIAL

CSTL

ADDITIONAL DATA

(8) 60 MMAND(2) 70 MM DIA HOLE,

FOR CYLINDER LINER OF M.A.N. DIESEL ENGINE

MODEL # 12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#050.03.002" MAN B&W.L48/60B.050.03.002

"MAN B&W

L48/60B" "BEARING,ROD END

ROLLING ELEMENT

SPHERICAL

STYLE

2 SHIELD

INSIDE DIAMETER

20 MM

OUTSIDE DIAMETER

50 MM

WIDTH

25 MM (0.9843 IN)

SHANK DIAMETER

19.5 MM

THREADS

1.50 MM MALE

HOUSING MATERIAL

CSTL

STANDARD/SPECIFICATION

ASTM

ADDITIONAL DATA

SPHERICAL, FOR SPEED GOVERNOR OF M.A.N.

DIESEL ENGINE MODEL # 12V48 60B

SERIAL# 1135341 AND 1135342.

MAN DIESEL

P/N#140.04.A11" MAN B&W.L48/60B.140.04.A11

"MAN B&W

L48/60B" "BEARING,ROD END

ROLLING ELEMENT

SPHERICAL

STYLE

2 SHIELD

INSIDE DIAMETER

19.5 MM

OUTSIDE DIAMETER

50.5 MM

WIDTH

25 MM (0.9843 IN)

SHANK DIAMETER

23 MM

THREADS

1.50 MM FEMALE

HOUSING MATERIAL

CSTL

STANDARD/SPECIFICATION

ASTM

ADDITIONAL DATA

SPHERICAL, 140.04 SPEED GOVERNOR,

FOR M.A.N. DIESEL ENGINE MODEL # 12V48 60B

SERIAL # 1135341 AND 1135342.WISE.

MAN DIESEL

P/N#140.04.A13" MAN B&W.L48/60B.140.04.A13

"MAN B&W

L48/60B" Sealing ring MAN B&W.L48/60B.050.03.004

"MAN B&W

L48/60B" O-RING SEAL MAN B&W.L48/60B.050.03.012

"MAN B&W

L48/60B" "RING,BULK NOUN

PARENT EQUIPMENT/FUNCTION

SEALING.

ADDITIONAL DATA

PM PARTS, CYLINDER LINER GROUP,

FOR UNIT# 10&11, M.A.N. DIESEL ENGINE,

MODEL12V 48 60B,

SAMPLE S N 1135341&1135342,

ENGINE OUTPUT 12600 KW,

ENGINE SPEED 514 RPM,

ENGINE DIRECTION CLOCKWISE,

MAN DIESEL

P/N#050.03.013" MAN B&W.L48/60B.050.03.013

"MAN B&W

L48/60B" 0-RING SEAL MAN B&W.L48/60B.055.01.027

"MAN B&W

L48/60B" 0-RING SEAL MAN B&W.L48/60B.055.01.028

"MAN B&W

L48/60B" "SEAL,BULK NOUN

PARENT EQUIPMENT/FUNCTION

RING

SIZE

20 MM ID X 23 MM OD X 1 MM TH

MATERIAL

CU

ADDITIONAL DATA

FOR CYLINDER HEAD OF M.A.N. DIESEL ENGINE

MODEL # 12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#055.01.036" MAN B&W.L48/60B.055.01.036

"MAN B&W

L48/60B" 0-RING SEAL MAN B&W.L48/60B.055.01.043

"MAN B&W

L48/60B" 0-RING SEAL MAN B&W.L48/60B.055.01.053

"MAN B&W

L48/60B" 0-RING SEAL MAN B&W.L48/60B.055.01.054

"MAN B&W

L48/60B" 0-RING SEAL MAN B&W.L48/60B.055.01.055

"MAN B&W

L48/60B" 0-RING SEAL MAN B&W.L48/60B.055.01.056

"MAN B&W

L48/60B" 0-RING SEAL MAN B&W.L48/60B.055.01.066

"MAN B&W

L48/60B" "SPRING,COMPRESSION

SIZE

65 MM ID X 92 MM OD

WIRE SIZE

13.5 MM

LENGTH

270 MM

MATERIAL

CSTL

STANDARD/SPECIFICATION

DIN 2098

ADDITIONAL DATA

FOR EXHAUST VALVE GROUP OF M.A.N. DIESEL ENGINES, MODEL NO. 12V48 60B. COLOR SILVER

MAN DIESEL

P/N#114.01.003" MAN B&W.L48/60B.114.01.003

"MAN B&W

L48/60B" "BEARING,BALL

ROW

1

INSIDE DIAMETER

(36 MM X 43 MM X 91 MM)

OUTSIDE DIAMETER

(100.5 MM X 115 MM X 143 MM)

WIDTH

54.5 MM

SERIES

MEDIUM

STYLE

OPEN

CAGE MATERIAL

CSTL

STANDARD/SPECIFICATION

GOST 801

ADDITIONAL DATA

TYPE THRUST, FOR EXHAUST VALVE

GROUP OF M.A.N. DIESEL ENGINE MODEL # 12V48 60B

SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#114.01.A05" MAN B&W.L48/60B.114.01.A05

"MAN B&W

L48/60B" SEALING RING MAN B&W.L48/60B.162.02.009

"MAN B&W

L48/60B" "O-RING,BULK NOUN

INSIDE DIAMETER

75 MM

OUTSIDE DIAMETER

85 MM

WIDTH

5 MM

MATERIAL

RUBBER

COLOR

BLACK

SERVICE

FUEL

STANDARD/SPECIFICATION

ASTM D2000, SAE J200, ISO 3601-1, SAE AS568A, ASTM D1414, ASTM D2240 00, ISO 7619, ISO 868

ADDITIONAL DATA

SYSTEM PARENT EQUIPMENT INFORMATION

FOR FUEL INJECTION PUMP GROUP OF MAN (M.A.N.) DIESEL DRIVEN GENERATOR MODEL # 12V48 60B.

MAN DIESEL

P/N#200.02.013" MAN B&W.L48/60B.200.02.013

"MAN B&W

L48/60B" O-ring seal MAN B&W.L48/60B.200.02.014

"MAN B&W

L48/60B" "SEAL,BULK NOUN

PARENT EQUIPMENT/FUNCTION

SPRING ENERGIZED U CUP

SIZE

120 MM ID X 132 MM OD X 6 MM WD

MATERIAL

PLASTIC/STL

ADDITIONAL DATA

FOR FUEL INJECTION PUMP OF M.A.N. DIESEL ENGINE MODEL # 12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#200.02.015" MAN B&W.L48/60B.200.02.015

"MAN B&W

L48/60B" "SEAL,BULK NOUN

PARENT EQUIPMENT/FUNCTION

SHAFT

SIZE

28 MM ID X 40 MM OD X 7 MM WD

MATERIAL

STL/YARN

ADDITIONAL DATA

FOR FUEL INJECTION PUMP GROUP OF M.A.N.

DIESEL ENGINE MODEL # 12V48 60B

SERIAL# 1135341 AND 1135342.

MAN DIESEL

P/N#200.02.032" MAN B&W.L48/60B.200.02.032

"MAN B&W

L48/60B" 密封圈 MAN B&W.L48/60B.200.02.054

"MAN B&W

L48/60B" 辅助环 MAN B&W.L48/60B.200.02.055

"MAN B&W

L48/60B" "PIN,BULK NOUN

PARENT EQUIPMENT/FUNCTION

SPRING,FUEL INJECTION VALVE,DIESEL ENGINE

DIAMETER

(7.5 MM X 13.5 MM X 29 MM)

LENGTH

74 MM

MATERIAL

CSTL

STANDARD/SPECIFICATION

JSA JIS B 2808

ADDITIONAL DATA

FOR FUEL INJECTION VALVE OF M.A.N. DIESEL ENGINE MODEL # 12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#221.04.007" MAN B&W.L48/60B.221.04.007

"MAN B&W

L48/60B" "SEAL,BULK NOUN

PARENT EQUIPMENT/FUNCTION

RING

SIZE

14 MM ID X 18 MM OD X 1 MM TH

MATERIAL

CU

ADDITIONAL DATA

FOR PILOT VALVE AND EMERGENCY STOP PIPE

GROUP OF M.A.N. DIESEL ENGINE MODEL # 12V48 60B

SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#432.01.030" MAN B&W.L48/60B.432.01.030

"MAN B&W

L48/60B" "PIECE,BULK NOUN

PARENT EQUIPMENT/FUNCTION

JOINING,STARTING AIR PIPE,DIESEL ENGINE

SIZE

145 MM WD X 180 MM LG X 120 MM HT

MATERIAL

STL

ADDITIONAL DATA

(1) 63 MM HOLE, (1) 93 MM HOLE, PM PARTS, STARTING AIR PIPE GROUP, FOR M.A.N. DIESEL ENGINE MODEL # 12V48 60B.

MAN DIESEL

P/N#432.03.003" MAN B&W.L48/60B.432.03.003

"MAN B&W

L48/60B" "O-RING,BULK NOUN

STANDARD/SPECIFICATION

ASTM

ADDITIONAL DATA

PM PARTS FOR MAIN STARTING VALVE GROUP,

FOR UNIT# 10&11, M.A.N. DIESEL ENGINES,

MODEL 12V48 60B, SAMPLE S N 1135341 &1135342,

ENGINE OUTPUT 12600 KW,

ENGINE SPEED 514 RPM,

ENGINE DIRECTION CLOCKWISE

MAN DIESEL

P/N#432.22.005" MAN B&W.L48/60B.432.22.005

"MAN B&W

L48/60B" "PARENT EQUIPMENT/FUNCTION

BEARING, TURBOCHARGER

SIZE

95 MM ID X 170 MM OD X 12 MM TH

MATERIAL

BRS

STANDARD/SPECIFICATION

ASTM

ADDITIONAL DATA

BEARING CASING GROUP, FOR TURBOCHARGER,

MODEL # TCA77-40055, SAMPLE SERIAL # 1151149, AUXILIARIES OF MAN DIESEL ENGINES, MODEL 12V48 60B.

MAN DIESEL

P/N#517.075/TCA77" MAN B&W.L48/60B.517.075/TCA77

"MAN B&W

L48/60B" "BUSHING,BULK NOUN

PARENT EQUIPMENT/FUNCTION

BEARING CASING,TURBOCHARGER

SIZE

95 MM ID X 138 MM OD X 72 MM HT

MATERIAL

BRS

STANDARD/SPECIFICATION

SAE AS14237A

ADDITIONAL DATA

(2) 10 MM HOLES, BEARING CASING GROUP,

FOR TURBOCHARGER MODEL # TCA77-40055,

SAMPLE SERIAL # 1151149, AUXILIARIES OF MAN DIESEL ENGINES, MODEL # 12V48 60B.

MAN DIESEL

P/N#517.161/TCA77" MAN B&W.L48/60B.517.161/TCA77

"MAN B&W

L48/60B" "GASKET,BULK NOUN

PARENT EQUIPMENT/FUNCTION

BEARING CASING

DESIGN/CONSTRUCTION

RING JOINT

FORM/STYLE/SHAPE

ROUND

SIZE

210 MM ID X 275 MM OD X 1 MM TH

MATERIAL

NON ASBESTOS

STANDARD/SPECIFICATION

MIL-DTL-24696C

ADDITIONAL DATA

ITEM ADDITIONAL DESCRIPTION

(6) 12 MM DIA HOLES,

COMPRESSOR SIDE BEARING CASING GROUP

SYSTEM PARENT EQUIPMENT

FOR TURBOCHARGER MODEL # TCA77-40055,

SAMPLE SERIAL # 1151149 USED ON M.A.N. DIESEL ENGINE MODEL # 12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#517.185" MAN B&W.L48/60B.517.185

"MAN B&W

L48/60B" "BEARING,PLAIN

DESIGN

THRUST

SIZE

95 MM ID X 378 MM OD X 40 MM WD

MATERIAL

SSTL

HOUSING

OPEN

STANDARD/SPECIFICATION

ASTM

ADDITIONAL DATA

(6) 17 MM DIA HOLE, (3) 10 MM DIA THD,

THD SIZE 2.0 MM, BEARING CASING GROUP,

FOR TURBOCHARGER, MODEL TCA77-40055,

SAMPLE S N 1151149, AUXILIARIES OF M.A.N.

DIESEL ENGINE MODEL # 12V48 60B.

MAN DIESEL

P/N#517.153" MAN B&W.L48/60B.517.153

"MAN B&W

L48/60B" "ELEMENT,BULK NOUN

PARENT EQUIPMENT/FUNCTION

PUMP, DIESEL ENGINE

SIZE

166 MM DIA X 453 MM LG

MATERIAL

CSTL

STANDARD/SPECIFICATION

ANSI

ADDITIONAL DATA

WITH (8) 16 MM DIA THD,

THD SIZE 2.5 MM X (1) 19 MM DIA HOLE,

WITH BAFFLE SCREW, TO INCLUDE ITEMS C01 TO C14,

WITH FUEL INJECTION PUMP GROUP, FOR MAN DIESEL ENGINE MODEL # 12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#200.02.009" MAN B&W.L48/60B.200.02.009

"MAN B&W

L48/60B" "ELEMENT,BULK NOUN

PARENT EQUIPMENT/FUNCTION

PUMP, DIESEL ENGINE

SIZE

166 MM DIA X 453 MM LG

MATERIAL

CSTL

STANDARD/SPECIFICATION

ANSI

ADDITIONAL DATA

WITH (8) 16 MM DIA THD,

THD SIZE 2.5 MM X (1) 19 MM DIA HOLE,

WITH BAFFLE SCREW, TO INCLUDE ITEMS C01 TO C14,

WITH FUEL INJECTION PUMP GROUP, FOR MAN DIESEL ENGINE MODEL # 12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#200.02.009" MAN B&W.L48/60B.200.02.009

"MAN B&W

L48/60B" "SEAL,BULK NOUN

ADDITIONAL DATA

INSERT GROUP, FOR TURBOCHARGER, MODEL TCA77-40055, SAMPLE S N 1151149, AUXILIARIES OF MAN DIESEL ENGINES, MODEL 12V48 60B,

TYPE O-RING.

MAN DIESEL

P/N#540.015/TCA77" MAN B&W.L48/60B.540.015/TCA77

"MAN B&W

L48/60B" "SEAT,BULK NOUN

PARENT EQUIPMENT/FUNCTION

DIESEL ENGINE VALVE

SIZE

130 MM ID X (155 MM X 180 MM) OD X 65 MM HT

MATERIAL

STL

ADDITIONAL DATA

SYSTEM PARENT EQUIPMENT INFORMATION

FOR OUTLET VALVE OF M.A.N. DIESEL ENGINE

MODEL # 12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#055.01.025" MAN B&W.L48/60B.055.01.025

"MAN B&W

L48/60B" "NOZZLE,BULK NOUN

PARENT EQUIPMENT/FUNCTION

DIESEL ENGINE FUEL INJECTOR

SIZE

(45.5 MM X 56 MM) DIA X 120 MM LG

CONNECTION

SLIP-ON

MATERIAL

CSTL

STANDARD/SPECIFICATION

ISO 26982013

ADDITIONAL DATA

(2) 4 MM X (2) 5 MM X (2) 7 MM DIA HOLE, PM PARTS,

FUEL INJECTION VALVE WITH INJECTION NOZZLE GROUP, FOR M.A.N. DIESEL ENGINE MODEL # 12V48 60B.

MAN DIESEL

P/N#221.04.M" MAN B&W.L48/60B.221.04.M

"MAN B&W

L48/60B" "JOINT,EXPANSION

DESIGN

BELLOWS

SIZE

545 MM ID X 640 MM OD

LENGTH

200 MM

CONNECTION

FLANGED

MATERIAL

CSTL

MOVEMENT

AXIAL

STANDARD/SPECIFICATION

ASTM

ADDITIONAL DATA

PM PARTS, FOR EXHAUST PIPE OF MAN DIESEL ENGINE MODEL # 12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#289.03.008/COMPENSATOR" MAN B&W.L48/60B.289.03.008/COMPENSATOR

"MAN B&W

L48/60B" "CLAMP,BULK NOUN

PARENT EQUIPMENT/FUNCTION

V-PROFILE, EXHAUST PIPE

SIZE

610 MM ID X 650 MM OD X 45 MM WD

MATERIAL

SSTL

STANDARD/SPECIFICATION

EPDM

ADDITIONAL DATA

PM PARTS, FOR MAN DIESEL ENGINE MODEL #12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#289.03.009" MAN B&W.L48/60B.289.03.009

"MAN B&W

L48/60B" "JOINT,EXPANSION

DESIGN

BELLOWS

SIZE

240 MM ID X (330 MM X 375 MM) OD

LENGTH

160 MM

CONNECTION

FLANGED

MATERIAL

SSTL BELLOWS/STL FLANGE

MOVEMENT

AXIAL

STANDARD/SPECIFICATION

ASTM

ADDITIONAL DATA

ASZ TYPE, (8) 18 MM HOLES, PM PARTS,

FOR MAN DIESEL ENGINE MODEL # 12V48 60B

SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#289.03.011" MAN B&W.L48/60B.289.03.011

"MAN B&W

L48/60B" "JOINT,EXPANSION

DESIGN

BELLOWS

SIZE

450 MM ID X (600 MM X 700 MM) OD

LENGTH

205 MM

CONNECTION

FLANGED

MATERIAL

SSTL BELLOWS/STL FLANGE

MOVEMENT

AXIAL

STANDARD/SPECIFICATION

ASTM

ADDITIONAL DATA

WITH (32) 13 MM DIA HOLE, PM PARTS,

FOR CHARGE AIR COOLER OF MAN DIESEL ENGINE

MODEL # 12V48 60B SERIAL # 1135341 AND 1135342.

MAN DIESEL

P/N#322.09.010" MAN B&W.L48/60B.322.09.010

"MAN B&W

L48/60B" "RING,BULK NOUN

PARENT EQUIPMENT/FUNCTION

COMPRESSION

ADDITIONAL DATA

PM PARTS, PISTON GROUP, FOR UNIT# 10&11,

M.A.N. DIESEL ENGINES, MODEL 12V48 60B,

SAMPLE S N 1135341&1135342,

ENGINE OUTPUT 12600KW,

ENGINE SPEED 514 RPM,

ENGINE DIRECTION CLOCKWISE,

MAN DIESEL

P/N#034.10.A" MAN B&W.L48/60B.034.10.A

"MAN B&W

L48/60B" "RING,BULK NOUN

PARENT EQUIPMENT/FUNCTION

COMPRESSION

ADDITIONAL DATA

PM PARTS, PISTON GROUP,

FOR UNIT# 10&11, M.A.N. DIESEL ENGINES,

MODEL 12V48 60B,  SAMPLE S N 1135341&1135342,

ENGINE OUTPUT 12600 KW,

ENGINE SPEED 514 RPM,

ENGINE DIRECTION CLOCKWISE,

MAN DIESEL

P/N#034.10.B" MAN B&W.L48/60B.034.10.B

"MAN B&W

L48/60B" "RING,BULK NOUN

PARENT EQUIPMENT/FUNCTION

OIL CONTROL.

ADDITIONAL DATA

PM PARTS, PISTON GROUP,

FOR UNIT# 10&11, M.A.N. DIESEL ENGINES,

MODEL 12V48 60B, SAMPLE S N 1135341&1135342,

ENGINE OUTPUT 12600 KW,

ENGINE SPEED 514 RPM,

ENGINE DIRECTION CLOCKWISE,

MAN DIESEL

P/N#034.10.C" MAN B&W.L48/60B.034.10.C
