SHIKAWAJIMA-HARIMA VTR201WP PRODUCTS–A11

SHIKAWAJIMA-HARIMA VTR201WP

PART NAME

PART NUMMBER

Nozzle ring

30

Turbine diffuser

30425

Nozzle

3308

Safety plate

3302

Hexagonal screw

3303

Sealing ring

3711

Piston ring

3712

Double-ball bearing,blower bush

320

Inner bearing bush

321

Out bearing bush

322

Damping sping radial

323

Damping sping axial

324a

Oil baffle plate

3270

Oil collector disc

329

Lubricating disc

330

Ball bearing turbine side

380

sealing bush

725

sealing bush

506

Lock disc

20809

Ring nut

20810

Oil buffer plate

50910
