111744Z-18-149

"Comments: BRAKE TEST KIT - direct type - BRACKET TYPE (""SIMPLIFIED"")

Enerpac cylinder model: RC-5013

Capacity: 50 ton

Stroke: 337 mm

Effective piston area: 71 ,20 cm2

Manometer: GP-10S (bar/psi)

F-28 Instruction Manual For Deck Machinery  page 275, 68

Hyundai Mipo H 0028        07.08.01             page 9 of 15

consists of the following elements:

Hydraulic jack for winch brake test

Capacity 50 tons

Length of stroke 337 mm

Weight 36,3 kg

DRG./ART No.STANDARD   002670.04600

F-28 Instruction Manual For Deck Machinery  page 275, 68

Hand pump for hydraulick jack

Pressure 700 bar

Tank capacity 2294 cm3

Weight 11,6 kg

DRG./ART No.STANDARD   002780.00700

F-28 Instruction Manual For Deck Machinery  page 275, 68

Manometer

Model: GP-10S

Units: 0-700 bar

0-10000 psi

DRG./ART No.STANDARD   002780.02200

F-28 Instruction Manual For Deck Machinery  page 275, 68, 73" """Hydraulic jack for winch brake test

Capacity 50 tons

Length of stroke 337 mm

Weight 36,3 kg

DRG./ART No.STA""

" HYUNDAI MIPO DOCKYARD
