HYUNDAI 8 H17/21V Generator Sets

Korea’s first high speed engine, H17/21V is a different design concept to the existing HiMSEN engine, with 1,800 rpm (1,500 rpm), a high output of 160 kW (140 kW) per cylinder at prime power, and a compact structure. The weight ratio per kilowatt of the H17/21V engine will average about one third less than the current 4-stroke diesel engine. It can be used for marine propulsion, emergency generator sets and diesel power plants. It is a state-of-the-art diesel engine available up to a maximum output of 3,200 kW and also satisfies IMO Tier II regulations for emissions, and the lower SFOC. The new H17/21V was developed based on the advanced HiMSEN engine concept and Hi-Touch technology. It also features

Structure strength minimizing heat load, noise and vibration

Operating system based on dynamic analysis for high precision

Highly efficient turbocharging for the best performance

Advanced Miller timing

Crown shape and selection of nozzle specification for excellent

combustion performance

Efficient lubrication and cooling system

HiMSEN H17/21V high speed engine marks the birth of a new era in earth-friendly engines, boasting a compact structure and simple

exterior sure to influence the industry.

Main Features

Performance characteristics

High Output in the similar range engines

Low Fuel Oil Consumption

Quick acceleration & load response

Maintenance

Easier maintenance by modularized design

Minimal the number and kind of

components

Earth-friendly engine

Low NOx emissions

Complies with IMO Tier II

Low Vibration & Noise

Marine

Naval Ship

Propulsion System

Generating Sets

Stationary

Power Plant

Packaged Power Station

Pre-fabricated Power Plant

Emergency Generating Sets

Technical Data

SPECIFICATION

UNIT

HYUNDAI H17/21V

BORE / STROKE

MM

170 / 210

170 / 210

SWEPT VOLUME

LITER/CYL.

4.77

4.77

BANK ANGLE

90

90

ENGINE SPEED

RPM

1500

1800

FREQUENCY

HZ

50

60

PISTON SPEED

M/S

10.5

12.6

MEAN EFFECTIVE PRESSURE(BMEP)

BAR

23.5

22.4

ENGINE TYPE

SPEED

RATED OUTPUT AT

CONTINUOUS POWER

PRIME POWER

STAND-BY POWER

ENG KW

GEN KW

ENG KW

GEN KW

ENG KW

GEN KW

HYUNDAI 8 H17/21V

1500RPM

1008

963

1120

1070

1232

1177

HYUNDAI 8 H17/21V

1800RPM

1152

1100

1280

1222

1408

1345

ENGINE TYPE

DIMESNSION MM

DRY MASS TON

A

B1

C1

H

ENG 2

GENSET 1.3

HYUNDAI 8 H17/21V

1730

1993

3723

2100

4.9

9.6

Remark

1) Depending on alternator.

2) Without common bed.

3) With Generator & Common bed (Maker : HHI-EES)

P: Free passage between the engines, width 600 mm and height 2,000 mm

Note) All dimensions and weight are approximate value and subject to change without notice.
