120949W-Cooler spare parts

FOR MAIN ENGINE AIR COOLER

Makers: DONGHWA ENTEC

Manufacturing No. DHM34620-A

Dwg and other data:  AIR COOLER FOR 6S46MC-C TIER 2 ENGINE

AIR COOLER PART NO. A19-325476-7

Heater tubes bundle, complete, with flange

Heater nameplate details: maker DongHwa Entec, cod

e LR, sn M19120-K; Manuf. Date 02/2012, Designatio

n number DHUH-M125ASS-5;Flange dimensions: T hickne

ss 23 mm; DIA 250 mm; 8 holes' x dia.17 mm; pitch

210 mm
