081138J-KASHIWA

"S. NO: TS3000;

MAKER: KASHIWA;

MODEL: PROJECT NO. : ISZ-3373;

INERT GAS SYSTEM -PNEUMATIC OPERATED BUTTERFLY

UPTAKE VALVE" "BOILER UPTAKE VALVE BUTTERFLY VALVE ; NOMINAL SIZE: 700A ,

PCD: 820 MM ,

FLANGE OUTER DIA: 875 MM,

FLANGE THICKNESS: 26 MM,

DOUBLE FLANGE TYPE,

NO OF BOLT HOLE FOR EACH FLANGE: 24 ,

HOLE DIA: 27 MM ,

FLANGE TO FLANGE : 300 MM ,

VALVE NO: PV-1,2

VALVE TO BE SUPPLY WITH OUT PNEUMATIC ACTUATOR (PNEUMATIC CYLINDER); DRAWING NO: H-47969" KASHIWA.NA.0501

  Metallic Gaskets.
