YANMAR DIESEL ENGINE PARTS 8N330-EN

TYPE: YANMAR 8N330-EN

 S/N:20068004

 FIG-18

 1 Exhaust valve seat cooling item 17 Part No.: 132654-11850

 2 Exhaust valve, item 3 Ni80 Part No.: 132654-11122

 3 Suction valve, item 2 Part No.: 132653-11100

 4 Suction valve seat, Item 13 Part No.: 132654-11840

 FIG-4

 5 O-Ring Item5 Part No.: 24326-000300

 6 O-Ring Item6 Part No.: 24316-000280

 7 O-Ring Item10 Part No.: 24316-000210

 8 O-Ring Item 11 Part No.: 24316-000240

 9 Cooling chamber assy Item1 Part No.: 132654-01303

 10 SW connect pipe 8 Item3 Part No.: 132654-01361

 11 SW connect pipe 10 Item 9 Part No.: 153605-01442

 12 SW connect pipe 15 Item 2 Part No.: 132654-01351

 13 Packing Item 12 Part No.: 132654-01710

 Fig – 19

 14 Sealed gasket Item 27 Part No.: 132654-11310

 Fig – 37

 15 Piston ring №1 Item8 Part No.: 132654-22190

 16 Piston ring №2 Item 9 Part No.: 132654-22150

 17 Piston ring №3 Item 10 Part No.: 132654-22160

 18 Piston ring №4 Item 11 Part No.: 132654 22230

 Fig – 22

 19 Gasket Item 5 Part No.: 132654-13201

 Fig – 20

 20 Sealed gasket Item 5 Part No.: 132654-12320
