Daihatsu DIESEL ENGINE PARTS 6Dk – 20 Rating: 830 Ps X 720 Rpm

Type:Daihatsu 6Dk – 20 Rating: 830 Ps X 720 Rpm

 4-Cycle Turbocharger- Fresh Water Cooled Diesel Engine

 S.N.:- 0470 / 471 / 472

 Engine Side Cover

 1 O-Ring Part No.: E200350240

 Cylinder Liner

 2 Protect Ring Part No.: E205050070

 Cylinder Head ( Nozzle:Cooling Type)

 3 Gasket , Cylinder Head Part No.: E2056501802

 4 Gasket Cooling Water Connector Part No.: E205650560Z

 5 O-Ring Part No.: Z560102235ZZ

 Exhaust Valve

 6 Exhaust Valve-1 nimonic Part No.: E205850040

 Starting Valve Part No.:

 7 O- Ring Part No.: Z5601Q4235ZZ

 Valve Operating Device

 8 O- Ring Part No.: Z560101424ZZ

 Fuel Oil Injection Block

 9 Oring Part No.: Z560103235DZ

 10 O- Ring Part No.: E206250120

 Fuel Injection Device

 11 O- Ring Part No.: Z560105035DZ

 12 O- Ring Part No.: Z560104835DZ

 13 Nozzle Dfl140Te2810 Part No.: E206250290

 14 Pin .Nozzle Dowel Part No.: AE01062021

 15 Inlet Connector Part No.: E206252300

 Fuel Oil Filters

 16 Element Assembly 200 Me Part No.: Y529000301

 17 Packing (Casing) Part No.: Y529000113

 Lubricating Oil Filter

 18 Element Assembly Part No.: Y529000287

 19 Packing (Casing) Part No.: Y529000107

 Turbocharger Lubricating Oil Filter

 20 Packing (Casing) Part No.: Y529000104

 Intake & Exhaust Tappet

 21 Rubber Seal Push Rod Part No.: E206650140

 Piping Part

 22 Banjo Plug 1/8 Part No.: X54S2Q1QQ0ZZ

 23 Banjo Plug 1/4 Part No.: X54202000ZZ

 24 Gasket 13 Part No.: Z56500130DZZ

 TYPE: DAIHATSU 5DK-20

 S/N No.I: DK520Z0384 No.2: DK520Z0385 No.3: DK520Z0386 Part No.:

 Cylinder Head

 1 Gasket. Cylinder Head Part No.: E205650180

 2 Gasket. Cooling Water Connector Part No.: E 205650560

 3 Gasket. Intake Monifold Bend Part No.: E 202050070

 4 Gasket, Exhaust Monifold Part No.: E202150270

 5 Valve Steam Seal Part No.: E 205650320

 6 Seat, Exhaust Valve Metco Part No.: E 205650090

 7 Seat, Intake Valve Part No.: E 205650060

 Fuel Injection Device

 8 Fuel Oil Injection Nozzle Dlf 140 Te 3010 Part No.: E 206250300

 9 Inlet Connector Part No.: E 206252300

 10 Gasket Part No.: Z 565001920ZZ

 Piston Part No.:

 11A Piston Ring-1 Part No.: E205150240

 11B Piston Ring-1 Part No.: E205150240

 12 Piston Ring -2 Part No.: E205150200

 13 Piston Ring -3 Part No.: E205150170

 14 Oil Ring Part No.: E205150230

 15 Thermometer-500 C Part No.: Y215004240

 16 Thermometer – 500 C Part No.: Y215004160

 Connecting Rod

 17 Crankpin Bearing Shell Part No.: E205250010

 Turbocharger Type- Rh143

 18 T/C Lube Oil Filter Packing Part No.: Y529000104

 19 Turbine Shaft Part No.: 10-1

 20 Seal Ring Part No.: 10-7

 21 O-Ring Part No.: 50-6

 22 Floating Journal Bearing Part No.: 60-1

 23 Thrust Bearing Part No.: 60-2

 24 Heat Shield Part No.: 50-7

 25 Spring Lock Washer Part No.: 90-9

 26 Hexagon Head Bolt M8X16 Part No.: 70-3

 27 Start Air Pressure Regulator Part No.: B1067-0982
