MAN B&W DIESEL ENGINE PARTS V32/40

TYPE ：MAN V32/40

 1 SEALING RING Part No.: 517.064

 2 HEXAGON BOLT Part No.: 517.065

 3 HEXAGON BOLT Part No.: 517.068

 4 HEXAGON BOLT Part No.: 517.082

 5 SEAL Part No.: 517.116

 6 RUBBER BOARD Part No.: 517.018

 7 SCREW Part No.: 517.028?

 8 HEXAGON NUT Part No.: 517.053

 9 HEXAGON BOLT? Part No.: 517.055

 10 SEAL RING Part No.: 517.064???

 11 PICK UP SPEED Part No.: 071.10.029

 12 PLUG FOR SENSOR PICKUP Part No.: 071.10.031

 13 PRESSURE TRANSMITTER Part No.: 280.34.A40

 14 PRESSURE TRANSMITTER Part No.: 280.34.A41

 15 SENSOR PT100 TEMPERATURE OF SPLASH Part No.: 413.19.001

 16 SENSOR SPEED TURBINE Part No.: 562.040

 17 TERMINAL BOX FOR TURBINE ROTATION SENSOR Part No.: 562.083

 18 Tachometer RPM (SPEED RPM WINDOW IN THE ENGINE) Part No.: 125.XX.140

 19 TURBINE TEMPERATURE SENSOR SIDE A and B Part No.: 403.NK.003

 20 “0 A 16 GAUGE BAR THREAD 1/2 BSP

 STRAIGHT OUT CASH DIM 100mm (WIKA) ” Part No.: 125.XX.050

 21 GAUGE 0 A 6 BAR Part No.: 125.XX.047

 22 0 A 40 GAUGE BAR Part No.: 125.XX.049

 23 0 A 10 GAUGE BAR Part No.: 125.XX.048?

 24 VALVE AIR CONTROL AIR Part No.: 125.98.409

 25 TEMPERATURE SENSOR Part No.: 125.98.B

 26 TEMPERATURE SENSOR GAS ENGINE Part No.: 125.98.C

 27 Teminal BOX FOR SENSOR ENGINE BEARING Part No.: 408.03.011

 28 TERMOMETRO Part No.: 447.36.136

 29 TEMOMETRO CHARGE AIR Part No.: 280.04.022

 30 UPPER BEARING Part No.: 030.02.A

 31 LOWER BEARING Part No.: 030.02.B

 32 COMPRESSION RING Part No.: 034.12.A

 33 SEGMENT RING DIAM Part No.: 034.12B

 34 OIL SCRAPER RING Part No.: 034.15.004

 35 PISTON DIAMETER Part No.: 034.12.003

 36 PISTON SKIRT Part No.: 034.12.004

 37 RUBBER BOARD Part No.: 050.07.007

 38 RUBBER BOARD Part No.: 050.07.024

 39 RUBBER ORING Part No.: 050.07.032

 40 SEAL RING Part No.: 050.07.034

 41 PLASTIC ORING Part No.: 055.10.051

 42 ROUND SEAL RING Part No.: 055.10.070

 43 LOUGR-HEAD COVER Part No.: 111.04.004

 44 ORING RUBBER BOARD Part No.: 111.04.D06

 45 CONE INTAKE VALVE OF THE PLASMA NITRACAO Part No.: 113.04.10

 46 SET OF WEAR PARTS Part No.: 113.04.020

 47 BALL AXIAL Part No.: 114.03.A03

 48 CONE OF ESCAPE VALVE NITRETACO THE PLASMA Part No.: 114.03.012

 49 WASHERN SEAL ORING Part No.: 200.08.043

 50 SEAL Part No.: 200.08.032

 51 RUBBER RING Part No.: 200.08.071

 52 BICO GUN 13X0.39X82 Part No.: 221.04.M

 53 SEAL RING Part No.: 221.04.012

 54 SPRING PLATE Part No.: 221.04.008

 55 ORING RUBBER BOARD Part No.: 221.04.020

 56 RUBBER ORING Part No.: 280.04.013

 57 AXIAL CONPENSATOR Part No.: 289.89.009

 58 V-PROFILE CLAMP Part No.: 289.89.012

 59 INTERCOOLER Part No.: 322.17.06

 60 THREAD PIECE Part No.: 434.17.001?

 61 FEEDER FUEL INJECTION SYSTEM Part No.: 434.17.010

 62 BUSH Part No.: 434.20.003

 63 GASKET Part No.: 434.20.009

 64 SEAL SET Part No.: 434.20.018

 65 PISTON Part No.: 434.20.020

 66 ORING RUBBER BOARD Part No.: 434.39.051

 67 WEDGE LOCK HOUSING CENTRAL Part No.: 501.005

 68 STUD SCREW Part No.: 501.006

 69 KEY LOCKING WASHER Part No.: 501.007

 70 HEXAGON NUT Part No.: 501.008
